| Home > Products > Bio Metric |
|
SENTRY is the state of the art biometric system by adopting fingerprint technology, which has excellent biometric security and user's convenience. Designed and manufactured with the sensor and algorithm developed by SreeGo's superior biometric technology , it has very accurate and speedy fingerprint recognition rate while a user can build very robust security system at inexpensive cost. Also if using server management program of which network configuration and functions have been strengthened, you may advantageously apply it for Access Control System and Time and Attendance Management of enterprise level.
Applications:
- IBS Building
- Bank and Financial institutes
- Factory
- Hotel
- Laboratories & Computer center
- Time & Attendance Application
Features:
- Suitable for diverse applications through high speed network (LAN)
- Suitable for Time & Attendance management by supporting functional keys (attendance, going out, return)
- Strengthening user's setting (ID digits, voice information, sensor option, operation mode etc.)
- Improving user's convenience by Auto-on, short ID, Group matching function
- Supports various security type by the combination of authentication methods (fingerprint, password, RF Card )
General Comparison |
Item |
Description |
| Product |
Fingerprint Access Controller |
| Fingerprint Sensor |
Optical / Capacitance Type |
| Resolution |
500 DPI |
| Network |
LAN(10Base-T, 10Mbps), DHCP |
| Authentication Mode |
1:1, 1:N, Group, short ID matching |
| Authentication Facts |
Finger, Password, RF Card (HID compatible) |
| User |
2000 User per 2 Finger / 4000 User per 1 Finger |
| Authentication Time |
T < 1 sec |
| Authentication Rate |
FRR: 1 / 1000 FAR:1 / 100000 |
| Function Key |
F1,F2,F3,F4 |
| Output of Power |
EM Lock, Dead Bolt, Auto-door |
| Communication |
Wigand(26 Bit / 34 Bit) Output, Rs232 |
| Display |
128 * 64 Pixel LCD |
| Size |
201.5(w) * 135(L) * 45(H) |
| Operating Temp |
-10C~40C |
| power |
12V/24V |
| Certifications |
CE, FCC, UL |
|
Interface:
- RS-232 15 pin D connector (Optional:USB port)
- Baud rate from 300 to 115,200 bits / s
- Autobauding (300 to 38,400 bits / s)
- Power supply through 2 pin socket
Deliverables:
- Universal AC Adapter
- PC Communication Cable
Integration:
Optional integration with the following are readily available:
- Display (LCD/Graphic)
- Customizable Keypad
- Smart card Reader
- GSM (for Mobile Applications)
- Buzzer/LED (for indication)
- Thermal/Mechanical Printer
|
|
|
